DXL COUNTERTOP PRECIOUS METAL ANALYSER

Add to wishlist
SKU: N/A
Add to wishlist

$700.00

Compare

Description

Specifications
ApplicationsNon-destructive method to test the purity and chemistry of precious metals
Data Memory64MB internal system memory/ 128MB internal user storage
Data StorageInternal >10,000 readings with spectra
Data TransferUSB
DescriptionNiton DXL Precious Metal Analyzer
Detector TypeHigh-performance Si-PIN semiconductor
Display TypeColor touch-screen display
Item DescriptionNiton DXL Precious Metal Analyzer
Height (English)10.4 in.
Height (Metric)265 mm
Length (English)15.6 in.
Length (Metric)396 mm
Width (English)8.1 in.
Width (Metric)206 mm
Length (English) Chamber6.9 in.
Length (Metric) Chamber172 mm
Height (English) Chamber5.2 in.
Height (Metric) Chamber133 mm
Width (English) Chamber7.2 in.
Width (Metric) Chamber184 mm
Optional Accessories3mm small-spot focus feature; Additional battery pack; External battery charger; Locking shielded carrying case
Power Consumption80μA
Security FeaturesPassword-protected user security
Standard AccessoriesOne 7.2V 4-cell lithium-ion battery pack (charges in the instrument while on external power); 110/220V AC adapter; USB PC connection cable; Thermo Scientific™ Niton Data Transfer (NDT™) PC software; 8mm measurement area; Internal CCD camera for precise sample positioning; Adhesive Tack for stabilization of samples; Spare puncture-resistant x-ray windows
Tube TypeAg anode 45kV maximum, 80µA maximum
Tube Voltage45 kV
Weight (English)17 lb.
Weight (Metric)7.7 kg
Voltage45 kV
System Electronics400MHz ARM 11 CPU; 300MHz dedicated DSP; 80MHz ASICS DSP for signal processing; 4096 channel MCA;
Data EntryTouch-screen keyboard, user-programmable pick lists
LicensingVaries by region. Contact your local distributor.
Dimensions (L x W x H)15.6 x 8.1 x 10.4 in. (396 x 206 x 265 mm)
Certifications/ComplianceCE, RoHS
Unit SizeEach
